6208E Deep Groove Ball Bearing Self Aligning For Industrial / Household

1
MOQ
6208E Deep Groove Ball Bearing Self Aligning For Industrial / Household
Features Gallery Product Description Chat Now
Features
Specifications
Type: Deep Groove Ball Bearing
Inner Diameter: 40 Mm
Outer Diameter: 80 Mm
Thickness: 18 Mm
Weight: 0.36 Kg
Color: Natural Metal Color
Highlight:

6208E Deep Groove Ball Bearing

,

6208E Bearing

,

Deep Groove Ball Bearing Self Aligning
Basic Infomation
Place of Origin: CHINA
Brand Name: Kesle
Model Number: 6208E
Payment & Shipping Terms
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union, MoneyGram,PayPal
Product Description

6208E Is A Deep Groove Ball Bearing For Industrial And Household Appliances

1. Basic Type of the Product

    Deep groove ball bearings are representative rolling bearings with a wide range of applications. They are suitable for operation at high rotational speeds, even extremely high rotational speeds, and are highly durable, requiring little frequent maintenance.
     This type of bearing features a low friction coefficient, high limiting speed, simple structure, low manufacturing cost, and ease of achieving high manufacturing precision. With a wide range of sizes and diverse configurations, they are used in industries such as precision instruments, low-noise motors, automobiles, motorcycles, and general machinery, making them the most widely used type of bearings in the machinery industry.
    They mainly bear radial loads and can also withstand a certain amount of axial loads.

2. Core Specification Parameters

Item Parameter Description
Bore Diameter () 40 mm Matches the shaft diameter.
Outer Diameter ( ) 80 mm Dimension for installation space.
Width () 18 mm Thickness of the bearing.
Weight Approx. 0.37–0.38 kg Varies slightly based on sealing structure, etc.
Dynamic Load Rating () Approx. 31.3 kN Capacity to withstand radial dynamic loads.
Static Load Rating () Approx. 18.6 kN Load - bearing capacity under static or low - speed conditions.

3. Performance and Structural Advantages

3.1 Load and Speed Performance

  • It primarily bears radial loads, while also accommodating a certain degree of axial load (when radial clearance increases, axial load - bearing capacity improves, similar to the characteristics of angular contact ball bearings).
  • It excels in high - speed applications: With a limiting speed of 6,600 r/min for grease lubrication, it meets the high - speed operation requirements of motors, reducers, and other equipment.

3.2 Self - Aligning and Compensation Capability

A slight tilt (≤ 8′–16′, depending on clearance) between the inner and outer rings is allowed, compensating for installation errors and enhancing stability in complex working conditions.

3.3 Material and Manufacturing Process

It uses high - carbon chromium bearing steel (GCr15, fully quenched), which undergoes precision heat treatment and machining. This ensures excellent wear resistance and fatigue resistance, guaranteeing a long service life.

4. Application Fields

Thanks to its features of "high speed, low noise, and adaptability to multiple scenarios", the 6208E is utilized across numerous industries:



  • General Machinery: Core transmission components such as motors, reducers, belt conveyors, idlers, and hoists.
  • Transportation Equipment: Transmission systems of automobiles and motorcycles.
  • Livelihood and Industrial Sectors: Medical devices, agricultural machinery, office equipment (e.g., fans), household appliances (e.g., water pumps), and power tools.

6208E Deep Groove Ball Bearing Self Aligning For Industrial / Household 0

6208E Deep Groove Ball Bearing Self Aligning For Industrial / Household 1

Tag:

Low Friction Ball Bearing

High Precision Ball Bearing

Low Noise Ball Bearing
